Flange Fittings
Orifice Flanges
Precision-engineered orifice flanges designed for reliable flow measurement connections, secure pipe assembly, and demanding industrial and process piping applications.
Product Type:
Orifice Flanges / Orifice Plate Flanges
Size Range:
1/2" NB to 48" NB
Standards:
ASME / ANSI / ASTM
Pressure Class:
150 to 2500 LBS
Application:
Flow Measurement, Industrial & Process Piping
About This Product
Orifice Flanges
GS MetalFit supplies orifice flanges designed for piping systems where a suitable flange arrangement is required for flow measurement using an orifice plate. These flanges provide the required connection points for installing and accessing an orifice plate and associated measurement components within the piping system.
Orifice flanges are commonly used in applications involving measurement of liquid, gas and other process fluids where controlled flow measurement is required. The flange arrangement can be supplied with suitable pressure classes, face configurations, sizes and material grades according to specified project requirements.
Our orifice flange range is available in stainless steel, carbon steel, alloy steel, duplex and super duplex steel, nickel alloys and copper-nickel materials.
The range includes slip on, SORF and slip on plate flange configurations available in stainless steel, duplex, super duplex, carbon steel, alloy steel, nickel alloys and cupro nickel grades. Products can be supplied in different sizes, pressure classes, face types, materials and dimensions according to specified project requirements.
Product Forms
Orifice Plate Flange
Orifice Raised Face Flange
Orifice Flat Face Flange
Orifice RTJ Flange
Weld Neck Orifice Flange
Slip On Orifice Flange
Stainless Steel Orifice Flange
Carbon Steel Orifice Flange
Alloy Steel Orifice Flange
Duplex Steel Orifice Flange
Super Duplex Orifice Flange
Nickel Alloy Orifice Flange
Copper Nickel Orifice Flange
Technical Specifications
Materials & Grades
Stainless Steel Orifice Flanges
Available in ASTM A182 / A240 grades including F304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H and 904L.
Alloy Steel Orifice Flanges
Available according to applicable ASTM / ASME A/SA 182 and A387 specifications, including F1, F5, F9, F11, F12, F22 and F91 grades.
Carbon Steel Orifice Flanges
Available in ASTM / ASME A/SA 105, A350, A181 LF2, A516 Grade 70, A36 and A694 grades including F42, F46, F52, F60, F65, F70, LF2 and LF3.
Duplex & Super Duplex Steel Orifice Flanges
Available in ASTM / ASME A/SA 182 grades including F44, F45, F51, F53, F55, F60, F61, 2205 (UNS S31803) and 2507 (UNS S32750).
Copper & Cupro Nickel Orifice Flanges
Available in selected copper and copper-nickel grades including UNS C10100, C10200, C10300, C10800, C12000, C12200, C70600 and C71500, including Cu-Ni 90/10 and Cu-Ni 70/30 grades.
Nickel Alloy Orifice Flanges
Available according to ASTM / ASME SB564, SB160, SB472 and SB162 specifications, including Nickel 200, Nickel 201, Monel 400, Monel K500, Inconel 800, Inconel 825, Inconel 600, Inconel 625, Inconel 601, Hastelloy C276 and Alloy 20.
Applications
Process Piping
Oil & Gas Facilities
Chemical & Petrochemical Plants
Power Generation Systems
Refinery Piping Systems
Industrial Process Equipment
General Engineering & Fabrication
Why Choose GS MetalFit?
Wide Material Selection
Orifice flanges are available in stainless steel, carbon steel, alloy steel, duplex, super duplex, nickel alloys and copper-nickel grades.
Multiple Pressure Classes
Products can be supplied in pressure classes from 150 LBS to 2500 LBS according to specified project requirements.
Different Face Configurations
Flat Face, Raised Face and Ring Type Joint options can be supplied for different piping and process requirements.
Flow Measurement Applications
Orifice flange arrangements are suitable for piping systems where an orifice plate is used as part of a flow measurement setup.
Project-Based Specifications
Size, material, dimensions, pressure class, flange face and applicable standards can be selected according to customer drawings and technical requirements.
Orifice Flanges Manufacturer & Supplier
GS MetalFit supplies Orifice Flanges and Orifice Plate Flanges for industrial, process and flow measurement applications. These specialized flanges are designed to accommodate an orifice plate within a piping system and provide suitable access for differential pressure measurement arrangements.
Our Orifice Flange range includes stainless steel, carbon steel, alloy steel, duplex, super duplex, nickel alloy and copper-nickel materials. Products can be supplied in different sizes, pressure classes, face configurations and material grades according to specified project requirements.
Orifice Flanges are available with Flat Face (FF), Raised Face (RF) and Ring Type Joint (RTJ) configurations. Products can be supplied according to applicable ASME B16.5, ASME B16.47, MSS SP-44, API 605, AWWA and other specified standards.
GS MetalFit supports enquiries for Orifice Flanges used in flow measurement systems, process piping, oil and gas facilities, chemical and petrochemical plants, refineries, power generation systems and general industrial applications.
Stainless Steel Orifice Flanges
GS MetalFit supplies stainless steel Orifice Flanges in commonly specified grades such as 304, 304L, 316, 316L, 321, 321H, 347, 347H and 904L. These flanges can be selected for process piping applications where corrosion resistance and dependable service performance are important.
Carbon Steel & Alloy Steel Orifice Flanges
Carbon steel and alloy steel Orifice Flanges are available for applications where mechanical strength and pressure-handling capability are important. Material options include ASTM A105, A350, A182 and A387 grades, subject to specified project requirements.
Duplex, Super Duplex & Nickel Alloy Orifice Flanges
For demanding service environments, GS MetalFit supplies duplex, super duplex and nickel alloy Orifice Flanges in grades such as UNS S31803, UNS S32205, UNS S32750, Nickel 200, Monel 400, Inconel 600, Inconel 625, Inconel 825, Hastelloy C276 and Alloy 20.
These material options can be considered for applications involving corrosion, aggressive process media, elevated temperatures and other specialized operating conditions.
Orifice Flanges for Industrial Flow Measurement Requirements
GS MetalFit supplies Orifice Flanges for domestic and international project requirements. Products can be prepared according to specified material grades, dimensions, pressure classes, flange faces, standards and customer drawings.
Whether the requirement is for stainless steel Orifice Flanges, carbon steel Orifice Flanges, duplex Orifice Flanges, nickel alloy Orifice Flanges or customized flange specifications, GS MetalFit supports product enquiries for flow measurement and industrial piping applications.
